Packing an impressive output of 1700 lumens in an incredibly compact housing, the EVO 1700 is tailored specifically for daily commuting in urban settings.
Without the need for a remote control, the EVO 1700SD connects directly to your bike’s Shimano Di2 system (wireless unit).
But please note the light is NOT compatible with SHIMANO E-BIKE SYSTEMS.
You will need a mount for this light, suggest MJ6272
Effortlessly adjust your light settings through Shimano Di2 buttons, as accessible as shifting gears.
**Paring Guide:**Initial Paring: Single click any button on the shifters to activate the SHIMANO Di2 system, then long press the light button for 1 second until the indicator flashes blue to enter pairing mode. Position the light to the rear derailleur within 30 cm. The indicator is constantly blue for 3 seconds, confirming a successful pairing.
**Note:**Before pairing, ensure your SHIMANO Di2 system has at least two unassigned buttons available to fully utilize product features.
Features:
- Max Output : 1700 LM
- Compatible with SHIMANO Di2 systemwireless unit)
- Unique combination of up-close low beam and far-reaching high beam
- Cut-Off Low Beam, glare-free for oncoming road users
- Robust Aluminum Housing
- Battery Source: 4000mAh Battery
- Lock Function
- Memory Function
- IPX6 Waterproof Rating
Mode |
Low Beam Low
|
Low Beam Medium |
Low Beam High |
High Beam Low |
High Beam Medium |
High Beam High |
Day Flash |
Night Flash |
|
Low |
Medium |
High |
Low |
Medium |
High |
Day Flash |
Night Flash |
Lumens |
200Lm |
400Lm |
800Lm |
400Lm |
800Lm |
1700Lm |
0-1700Lm |
400-1700Lm |
H:Min |
11:00 |
05:30 |
03:00 |
06:00 |
03:00 |
02:00 |
05:00 |
03:30 |
Specifications:
- Max Output: 1700 Lumens
- Max Runtime: 11 Hours
- Max Throw: 205 Meters
- Beam Intensity: 10520 CD
- light Source: High-efficiency LED
- Lens/Reflector Type: TIR optical lens
- Battery Source: 3.6V 4000mAh
- Charging Time: 5 hours (5V 1A)
- Body Material: Aluminum + Plastic
- Dimensions: 42 x 46 x 53 mm
- Weight: 51g
- Warranty: 2 years
Whats in the box:
- EVO1700SD Shimano Di2 Compatible Bike Light x 1
- USB-C charging cable x 1
- Tether x 1
- User manual x 1
- Magicshine APP user manual
